SGF23N60UFDM1TU Images
- Manufacturer: onsemi (ON)
- Category: Discrete Semiconductor Products~Transistors - IGBTs - Single Package/Case: TO-3P-3 Full Pack
- Description: IGBT 600V 23A 75W TO3PF
- COMPETITIVE PRICE and DELIVERY TIME
- Order with confidence, there are no lead times for in-stock products.
Download Datasheet (PDF)
SGF23N60UFDM1TU Specifications:
- MfrPart.: SGF23N60UFDM1TU
- Mfr: onsemi
- Description: IGBT 600V 23A 75W TO3PF
- Product Category: Discrete Semiconductor Products~Transistors - IGBTs - Single
- Package: Tube
- Series: -
- PartStatus: Obsolete
- IGBTType: -
- Voltage-CollectorEmitterBreakdown(Max): 600 V
- Current-Collector(Ic)(Max): 23 A
- Current-CollectorPulsed(Icm): 92 A
- Vce(on)(Max)@VgeIc: 2.6V @ 15V, 12A
- Power-Max: 75 W
- SwitchingEnergy: 115µJ (on), 135µJ (off)
- InputType: Standard
- GateCharge: 49 nC
- Td(on/off)@25°C: 17ns/60ns
- TestCondition: 300V, 12A, 23Ohm, 15V
- ReverseRecoveryTime(trr): 60 ns
- OperatingTemperature: -55°C ~ 150°C (TJ)
- MountingType: Through Hole
- Package/Case: TO-3P-3 Full Pack
- SGF23N60UFDM1TU onsemi (ON), IGBT 600V 23A 75W TO3PF, Discrete Semiconductor Products~Transistors - IGBTs - Single
