SBAW56WT1G onsemi DIODE ARRAY GP 70V 200MA SC75
SBAW56WT1G Images
SBAW56WT1G Images
SBAW56WT1G
  • Manufacturer: onsemi (ON)
  • Category: Discrete Semiconductor Products~Diodes - Rectifiers - Arrays Package / Case: SC-70, SOT-323
  • Description: DIODE ARRAY GP 70V 200MA SC75
  • COMPETITIVE PRICE and DELIVERY TIME
  • Order with confidence, there are no lead times for in-stock products.
Quickly Quote for You to Meet Your Target Price, Support Small Order Quantity with Fast Quick Delivery.
Download Datasheet (PDF)
SBAW56WT1G Datasheet
ELECTRONIC COMPONENTS, CHOOSE NHE ELECTRONICS
SBAW56WT1G Specifications:
  • Mfr Part: SBAW56WT1G
  • Mfr: onsemi
  • Description: DIODE ARRAY GP 70V 200MA SC75
  • Product Category: Discrete Semiconductor Products~Diodes - Rectifiers - Arrays
  • Item12: Tape & Reel (TR),Cut Tape (CT)
  • Series: -
  • Part Status: Active
  • Diode Configuration: 1 Pair Common Anode
  • Diode Type: Standard
  • Voltage - DC Reverse (Vr) (Max): 70 V
  • Current - Average Rectified (Io) (per Diode): 200mA (DC)
  • Voltage - Forward (Vf) (Max) @ If: 1.25 V @ 150 mA
  • Speed: Small Signal =< 200mA (Io), Any Speed
  • Current - Reverse Leakage @ Vr: 2.5 µA @ 70 V
  • Operating Temperature - Junction: -55°C ~ 150°C
  • Mounting Type: Surface Mount
  • Package / Case: SC-70, SOT-323
  • SBAW56WT1G onsemi (ON), DIODE ARRAY GP 70V 200MA SC75, Discrete Semiconductor Products~Diodes - Rectifiers - Arrays
