SBAT54XV2T5G Images
- Manufacturer: onsemi (ON)
- Category: Discrete Semiconductor Products~Diodes - Rectifiers - Single Package / Case: SC-79, SOD-523
- Description: SCHOTTKY DIODE SOD523
- COMPETITIVE PRICE and DELIVERY TIME
- Order with confidence, there are no lead times for in-stock products.
Download Datasheet (PDF)
SBAT54XV2T5G Specifications:
- Manufacturer Product Number: SBAT54XV2T5G
- Mfr: onsemi
- Detailed Description: SCHOTTKY DIODE SOD523
- Product Category: Discrete Semiconductor Products~Diodes - Rectifiers - Single
- Package: Tape & Reel (TR)
- Series: Automotive, AEC-Q101
- Part Status: Active
- Diode Type: Schottky
- Voltage - DC Reverse (Vr) (Max): 30 V
- Current - Average Rectified (Io): 200mA (DC)
- Voltage - Forward (Vf) (Max) @ If: 800 mV @ 100 mA
- Speed: Small Signal =< 200mA (Io), Any Speed
- Reverse Recovery Time (trr): 5 ns
- Current - Reverse Leakage @ Vr: 2 µA @ 25 V
- Capacitance @ Vr, F: 7.6pF @ 1V, 1MHz
- Mounting Type: Surface Mount
- Package / Case: SC-79, SOD-523
- Operating Temperature - Junction: -55°C ~ 150°C
- SBAT54XV2T5G onsemi (ON), SCHOTTKY DIODE SOD523, Discrete Semiconductor Products~Diodes - Rectifiers - Single
