SBAT54CWT1G onsemi DIODE ARRAY SCHOTTKY 30V SOT323
SBAT54CWT1G Images
SBAT54CWT1G Images
SBAT54CWT1G
  • Manufacturer: onsemi (ON)
  • Category: Discrete Semiconductor Products~Diodes - Rectifiers - Arrays Package / Case: SC-70, SOT-323
  • Description: DIODE ARRAY SCHOTTKY 30V SOT323
  • COMPETITIVE PRICE and DELIVERY TIME
  • Order with confidence, there are no lead times for in-stock products.
Quickly Quote for You to Meet Your Target Price, Support Small Order Quantity with Fast Quick Delivery.
Download Datasheet (PDF)
SBAT54CWT1G Datasheet
ELECTRONIC COMPONENTS, CHOOSE NHE ELECTRONICS
SBAT54CWT1G Specifications:
  • Mfr Part: SBAT54CWT1G
  • Mfr: onsemi
  • Description: DIODE ARRAY SCHOTTKY 30V SOT323
  • Product Category: Discrete Semiconductor Products~Diodes - Rectifiers - Arrays
  • Item12: Tape & Reel (TR),Cut Tape (CT)
  • Series: -
  • Part Status: Active
  • Diode Configuration: 1 Pair Common Cathode
  • Diode Type: Schottky
  • Voltage - DC Reverse (Vr) (Max): 30 V
  • Current - Average Rectified (Io) (per Diode): 200mA (DC)
  • Voltage - Forward (Vf) (Max) @ If: 800 mV @ 100 mA
  • Speed: Small Signal =< 200mA (Io), Any Speed
  • Current - Reverse Leakage @ Vr: 2 µA @ 25 V
  • Operating Temperature - Junction: -55°C ~ 125°C
  • Mounting Type: Surface Mount
  • Package / Case: SC-70, SOT-323
  • SBAT54CWT1G onsemi (ON), DIODE ARRAY SCHOTTKY 30V SOT323, Discrete Semiconductor Products~Diodes - Rectifiers - Arrays
