SB80W10T-TL-H Images
- Manufacturer: onsemi (ON)
- Category: Discrete Semiconductor Products~Diodes - Rectifiers - Arrays Package / Case: TO-252-3, DPak (2 Leads + Tab), SC-63
- Description: DIODE ARRAY SCHOTTKY 100V TPFA
- COMPETITIVE PRICE and DELIVERY TIME
- Order with confidence, there are no lead times for in-stock products.
Download Datasheet (PDF)
SB80W10T-TL-H Specifications:
- Mfr Part: SB80W10T-TL-H
- Mfr: onsemi
- Description: DIODE ARRAY SCHOTTKY 100V TPFA
- Product Category: Discrete Semiconductor Products~Diodes - Rectifiers - Arrays
- Item12: Tape & Reel (TR),Cut Tape (CT)
- Series: -
- Part Status: Not For New Designs
- Diode Configuration: 1 Pair Common Cathode
- Diode Type: Schottky
- Voltage - DC Reverse (Vr) (Max): 100 V
- Current - Average Rectified (Io) (per Diode): 8A
- Voltage - Forward (Vf) (Max) @ If: 800 mV @ 3 A
- Speed: Fast Recovery =< 500ns, > 200mA (Io)
- Current - Reverse Leakage @ Vr: 100 µA @ 50 V
- Operating Temperature - Junction: -55°C ~ 150°C
- Mounting Type: Surface Mount
- Package / Case: TO-252-3, DPak (2 Leads + Tab), SC-63
- SB80W10T-TL-H onsemi (ON), DIODE ARRAY SCHOTTKY 100V TPFA, Discrete Semiconductor Products~Diodes - Rectifiers - Arrays
SB80W10T-TL-H, onsemi authentic parts in stock from onsemi (ON) authorized distributors, order today, can ship immediately.
