SB560 Images
- Manufacturer: onsemi (ON)
- Category: Discrete Semiconductor Products~Diodes - Rectifiers - Single Package / Case: DO-201AD, Axial
- Description: DIODE SCHOTTKY 60V 5A DO201AD
- COMPETITIVE PRICE and DELIVERY TIME
- Order with confidence, there are no lead times for in-stock products.
Download Datasheet (PDF)
SB560 Specifications:
- Manufacturer Product Number: SB560
- Mfr: onsemi
- Detailed Description: DIODE SCHOTTKY 60V 5A DO201AD
- Product Category: Discrete Semiconductor Products~Diodes - Rectifiers - Single
- Package: Tape & Reel (TR),Cut Tape (CT)
- Series: -
- Part Status: Active
- Diode Type: Schottky
- Voltage - DC Reverse (Vr) (Max): 60 V
- Current - Average Rectified (Io): 5A
- Voltage - Forward (Vf) (Max) @ If: 670 mV @ 5 A
- Speed: Fast Recovery =< 500ns, > 200mA (Io)
- Reverse Recovery Time (trr): -
- Current - Reverse Leakage @ Vr: 500 µA @ 60 V
- Capacitance @ Vr, F: 380pF @ 4V, 1MHz
- Mounting Type: Through Hole
- Package / Case: DO-201AD, Axial
- Operating Temperature - Junction: -55°C ~ 150°C
- SB560 onsemi (ON), DIODE SCHOTTKY 60V 5A DO201AD, Discrete Semiconductor Products~Diodes - Rectifiers - Single
