SB10015M-TL-E Images
- Manufacturer: onsemi (ON)
- Category: Discrete Semiconductor Products~Diodes - Rectifiers - Single Package / Case: SC-70, SOT-323
- Description: RECTIFIER DIODE
- COMPETITIVE PRICE and DELIVERY TIME
- Order with confidence, there are no lead times for in-stock products.
Download Datasheet (PDF)
SB10015M-TL-E Specifications:
- Manufacturer Product Number: SB10015M-TL-E
- Mfr: onsemi
- Detailed Description: RECTIFIER DIODE
- Product Category: Discrete Semiconductor Products~Diodes - Rectifiers - Single
- Package: Bulk
- Series: -
- Part Status: Obsolete
- Diode Type: Schottky
- Voltage - DC Reverse (Vr) (Max): 15 V
- Current - Average Rectified (Io): 1A
- Voltage - Forward (Vf) (Max) @ If: 540 mV @ 1 A
- Speed: Fast Recovery =< 500ns, > 200mA (Io)
- Reverse Recovery Time (trr): 10 ns
- Current - Reverse Leakage @ Vr: 3 µA @ 7.5 V
- Capacitance @ Vr, F: 20pF @ 10V, 1MHz
- Mounting Type: Surface Mount
- Package / Case: SC-70, SOT-323
- Operating Temperature - Junction: -55°C ~ 150°C
- SB10015M-TL-E onsemi (ON), RECTIFIER DIODE, Discrete Semiconductor Products~Diodes - Rectifiers - Single
