RFP14N05L Images
- Manufacturer: onsemi (ON)
- Category: Discrete Semiconductor Products~Transistors - FETs, MOSFETs - Single SupplierDevicePackage: TO-220-3
- Description: MOSFET N-CH 50V 14A TO220-3
- COMPETITIVE PRICE and DELIVERY TIME
- Order with confidence, there are no lead times for in-stock products.
Download Datasheet (PDF)
RFP14N05L Specifications:
- MfrPart.: RFP14N05L
- Mfr: onsemi
- Description: MOSFET N-CH 50V 14A TO220-3
- Product Category: Discrete Semiconductor Products~Transistors - FETs, MOSFETs - Single
- Package: Tube
- Series: -
- PartStatus: Obsolete
- FETType: N-Channel
- Technology: MOSFET (Metal Oxide)
- DraintoSourceVoltage(Vdss): 50 V
- Current-ContinuousDrain(Id)@25°C: 14A (Tc)
- DriveVoltage(MaxRdsOnMinRdsOn): 5V
- RdsOn(Max)@IdVgs: 100mOhm @ 14A, 5V
- Vgs(th)(Max)@Id: 2V @ 250µA
- GateCharge(Qg)(Max)@Vgs: 40 nC @ 10 V
- Vgs(Max): ±10V
- InputCapacitance(Ciss)(Max)@Vds: 670 pF @ 25 V
- FETFeature: -
- PowerDissipation(Max): 48W (Tc)
- OperatingTemperature: -55°C ~ 175°C (TJ)
- MountingType: Through Hole
- SupplierDevicePackage: TO-220-3
- RFP14N05L onsemi (ON), MOSFET N-CH 50V 14A TO220-3, Discrete Semiconductor Products~Transistors - FETs, MOSFETs - Single
