RFD15P05 Images
- Manufacturer: onsemi (ON)
- Category: Discrete Semiconductor Products~Transistors - FETs, MOSFETs - Single SupplierDevicePackage: I-PAK
- Description: MOSFET P-CH 50V 15A I-PAK
- COMPETITIVE PRICE and DELIVERY TIME
- Order with confidence, there are no lead times for in-stock products.
Download Datasheet (PDF)
RFD15P05 Specifications:
- MfrPart.: RFD15P05
- Mfr: onsemi
- Description: MOSFET P-CH 50V 15A I-PAK
- Product Category: Discrete Semiconductor Products~Transistors - FETs, MOSFETs - Single
- Package: Tube
- Series: -
- PartStatus: Obsolete
- FETType: P-Channel
- Technology: MOSFET (Metal Oxide)
- DraintoSourceVoltage(Vdss): 50 V
- Current-ContinuousDrain(Id)@25°C: 15A (Tc)
- DriveVoltage(MaxRdsOnMinRdsOn): 10V
- RdsOn(Max)@IdVgs: 150mOhm @ 15A, 10V
- Vgs(th)(Max)@Id: 4V @ 250µA
- GateCharge(Qg)(Max)@Vgs: 150 nC @ 20 V
- Vgs(Max): ±20V
- InputCapacitance(Ciss)(Max)@Vds: 1150 pF @ 25 V
- FETFeature: -
- PowerDissipation(Max): 80W (Tc)
- OperatingTemperature: -55°C ~ 175°C (TJ)
- MountingType: Through Hole
- SupplierDevicePackage: I-PAK
- RFD15P05 onsemi (ON), MOSFET P-CH 50V 15A I-PAK, Discrete Semiconductor Products~Transistors - FETs, MOSFETs - Single
