RFD14N05 Images
- Manufacturer: onsemi (ON)
- Category: Discrete Semiconductor Products~Transistors - FETs, MOSFETs - Single SupplierDevicePackage: I-PAK
- Description: MOSFET N-CH 50V 14A I-PAK
- COMPETITIVE PRICE and DELIVERY TIME
- Order with confidence, there are no lead times for in-stock products.
Download Datasheet (PDF)
RFD14N05 Specifications:
- MfrPart.: RFD14N05
- Mfr: onsemi
- Description: MOSFET N-CH 50V 14A I-PAK
- Product Category: Discrete Semiconductor Products~Transistors - FETs, MOSFETs - Single
- Package: Tube
- Series: -
- PartStatus: Obsolete
- FETType: N-Channel
- Technology: MOSFET (Metal Oxide)
- DraintoSourceVoltage(Vdss): 50 V
- Current-ContinuousDrain(Id)@25°C: 14A (Tc)
- DriveVoltage(MaxRdsOnMinRdsOn): 10V
- RdsOn(Max)@IdVgs: 100mOhm @ 14A, 10V
- Vgs(th)(Max)@Id: 4V @ 250µA
- GateCharge(Qg)(Max)@Vgs: 40 nC @ 20 V
- Vgs(Max): ±20V
- InputCapacitance(Ciss)(Max)@Vds: 570 pF @ 25 V
- FETFeature: -
- PowerDissipation(Max): 48W (Tc)
- OperatingTemperature: -55°C ~ 175°C (TJ)
- MountingType: Through Hole
- SupplierDevicePackage: I-PAK
- RFD14N05 onsemi (ON), MOSFET N-CH 50V 14A I-PAK, Discrete Semiconductor Products~Transistors - FETs, MOSFETs - Single
RFD14N05, onsemi authentic parts in stock from onsemi (ON) authorized distributors, order today, can ship immediately.
