PZTA29 Images
- Manufacturer: onsemi (ON)
- Category: Discrete Semiconductor Products~Transistors - Bipolar (BJT) - Single Package/Case: TO-261-4, TO-261AA
- Description: TRANS NPN DARL 100V 0.8A SOT223
- COMPETITIVE PRICE and DELIVERY TIME
- Order with confidence, there are no lead times for in-stock products.
Download Datasheet (PDF)
PZTA29 Specifications:
- MfrPart.: PZTA29
- Mfr: onsemi
- Description: TRANS NPN DARL 100V 0.8A SOT223
- Product Category: Discrete Semiconductor Products~Transistors - Bipolar (BJT) - Single
- Package: Tape & Reel (TR),Cut Tape (CT)
- Series: -
- PartStatus: Active
- TransistorType: NPN - Darlington
- Current-Collector(Ic)(Max): 800 mA
- Voltage-CollectorEmitterBreakdown(Max): 100 V
- VceSaturation(Max)@IbIc: 1.5V @ 100µA, 100mA
- Current-CollectorCutoff(Max): 50nA
- DCCurrentGain(hFE)(Min)@IcVce: 10000 @ 100mA, 5V
- Power-Max: 1 W
- Frequency-Transition: 125MHz
- OperatingTemperature: -55°C ~ 150°C (TJ)
- MountingType: Surface Mount
- Package/Case: TO-261-4, TO-261AA
- PZTA29 onsemi (ON), TRANS NPN DARL 100V 0.8A SOT223, Discrete Semiconductor Products~Transistors - Bipolar (BJT) - Single
PZTA29, onsemi authentic parts in stock from onsemi (ON) authorized distributors, order today, can ship immediately.
