PN3563_D75Z Images
- Manufacturer: onsemi (ON)
- Category: Discrete Semiconductor Products~Transistors - Bipolar (BJT) - RF Package/Case: TO-226-3, TO-92-3 (TO-226AA) (Formed Leads)
- Description: RF TRANS NPN 15V 1.5GHZ TO92-3
- COMPETITIVE PRICE and DELIVERY TIME
- Order with confidence, there are no lead times for in-stock products.
Download Datasheet (PDF)
PN3563_D75Z Specifications:
- MfrPart.: PN3563_D75Z
- Mfr: onsemi
- Description: RF TRANS NPN 15V 1.5GHZ TO92-3
- Product Category: Discrete Semiconductor Products~Transistors - Bipolar (BJT) - RF
- Package: Tape & Box (TB)
- Series: -
- PartStatus: Obsolete
- TransistorType: NPN
- Voltage-CollectorEmitterBreakdown(Max): 15V
- Frequency-Transition: 1.5GHz
- NoiseFigure(dBTyp@f): -
- Gain: 14dB ~ 26dB
- Power-Max: 350mW
- DCCurrentGain(hFE)(Min)@IcVce: 20 @ 8mA, 10V
- Current-Collector(Ic)(Max): 50mA
- OperatingTemperature: -55°C ~ 150°C (TJ)
- MountingType: Through Hole
- Package/Case: TO-226-3, TO-92-3 (TO-226AA) (Formed Leads)
- PN3563_D75Z onsemi (ON), RF TRANS NPN 15V 1.5GHZ TO92-3, Discrete Semiconductor Products~Transistors - Bipolar (BJT) - RF
