PN2369 Images
- Manufacturer: onsemi (ON)
- Category: Discrete Semiconductor Products~Transistors - Bipolar (BJT) - Single Package/Case: TO-226-3, TO-92-3 (TO-226AA)
- Description: TRANS NPN 15V 0.2A TO92
- COMPETITIVE PRICE and DELIVERY TIME
- Order with confidence, there are no lead times for in-stock products.
Download Datasheet (PDF)
PN2369 Specifications:
- MfrPart.: PN2369
- Mfr: onsemi
- Description: TRANS NPN 15V 0.2A TO92
- Product Category: Discrete Semiconductor Products~Transistors - Bipolar (BJT) - Single
- Package: Bulk
- Series: -
- PartStatus: Obsolete
- TransistorType: NPN
- Current-Collector(Ic)(Max): 200 mA
- Voltage-CollectorEmitterBreakdown(Max): 15 V
- VceSaturation(Max)@IbIc: 250mV @ 1mA, 10mA
- Current-CollectorCutoff(Max): 400nA (ICBO)
- DCCurrentGain(hFE)(Min)@IcVce: 40 @ 10mA, 1V
- Power-Max: 350 mW
- Frequency-Transition: -
- OperatingTemperature: -55°C ~ 150°C (TJ)
- MountingType: Through Hole
- Package/Case: TO-226-3, TO-92-3 (TO-226AA)
- PN2369 onsemi (ON), TRANS NPN 15V 0.2A TO92, Discrete Semiconductor Products~Transistors - Bipolar (BJT) - Single
PN2369, onsemi authentic parts in stock from onsemi (ON) authorized distributors, order today, can ship immediately.
