PN2222TAR onsemi TRANS NPN 30V 0.6A TO-92
PN2222TAR Images
PN2222TAR Images
PN2222TAR
  • Manufacturer: onsemi (ON)
  • Category: Discrete Semiconductor Products~Transistors - Bipolar (BJT) - Single Package/Case: TO-226-3, TO-92-3 (TO-226AA) (Formed Leads)
  • Description: TRANS NPN 30V 0.6A TO-92
  • COMPETITIVE PRICE and DELIVERY TIME
  • Order with confidence, there are no lead times for in-stock products.
Quickly Quote for You to Meet Your Target Price, Support Small Order Quantity with Fast Quick Delivery.
Download Datasheet (PDF)
PN2222TAR Datasheet
ELECTRONIC COMPONENTS, CHOOSE NHE ELECTRONICS
PN2222TAR Specifications:
  • MfrPart.: PN2222TAR
  • Mfr: onsemi
  • Description: TRANS NPN 30V 0.6A TO-92
  • Product Category: Discrete Semiconductor Products~Transistors - Bipolar (BJT) - Single
  • Package: Tape & Box (TB)
  • Series: -
  • PartStatus: Obsolete
  • TransistorType: NPN
  • Current-Collector(Ic)(Max): 600 mA
  • Voltage-CollectorEmitterBreakdown(Max): 30 V
  • VceSaturation(Max)@IbIc: 1V @ 50mA, 500mA
  • Current-CollectorCutoff(Max): 10nA (ICBO)
  • DCCurrentGain(hFE)(Min)@IcVce: 100 @ 150mA, 10V
  • Power-Max: 625 mW
  • Frequency-Transition: 300MHz
  • OperatingTemperature: 150°C (TJ)
  • MountingType: Through Hole
  • Package/Case: TO-226-3, TO-92-3 (TO-226AA) (Formed Leads)
  • PN2222TAR onsemi (ON), TRANS NPN 30V 0.6A TO-92, Discrete Semiconductor Products~Transistors - Bipolar (BJT) - Single
