PN2222ATA onsemi TRANS NPN 40V 1A TO92-3
PN2222ATA Images
PN2222ATA Images
PN2222ATA
  • Manufacturer: onsemi (ON)
  • Category: Discrete Semiconductor Products~Transistors - Bipolar (BJT) - Single Package/Case: TO-226-3, TO-92-3 (TO-226AA) (Formed Leads)
  • Description: TRANS NPN 40V 1A TO92-3
  • COMPETITIVE PRICE and DELIVERY TIME
  • Order with confidence, there are no lead times for in-stock products.
Quickly Quote for You to Meet Your Target Price, Support Small Order Quantity with Fast Quick Delivery.
Download Datasheet (PDF)
PN2222ATA Datasheet
ELECTRONIC COMPONENTS, CHOOSE NHE ELECTRONICS
PN2222ATA Specifications:
  • MfrPart.: PN2222ATA
  • Mfr: onsemi
  • Description: TRANS NPN 40V 1A TO92-3
  • Product Category: Discrete Semiconductor Products~Transistors - Bipolar (BJT) - Single
  • Package: Cut Tape (CT),Tape & Box (TB)
  • Series: -
  • PartStatus: Active
  • TransistorType: NPN
  • Current-Collector(Ic)(Max): 1 A
  • Voltage-CollectorEmitterBreakdown(Max): 40 V
  • VceSaturation(Max)@IbIc: 1V @ 50mA, 500mA
  • Current-CollectorCutoff(Max): 10nA (ICBO)
  • DCCurrentGain(hFE)(Min)@IcVce: 100 @ 150mA, 10V
  • Power-Max: 625 mW
  • Frequency-Transition: 300MHz
  • OperatingTemperature: -55°C ~ 150°C (TJ)
  • MountingType: Through Hole
  • Package/Case: TO-226-3, TO-92-3 (TO-226AA) (Formed Leads)
  • PN2222ATA onsemi (ON), TRANS NPN 40V 1A TO92-3, Discrete Semiconductor Products~Transistors - Bipolar (BJT) - Single
