PN2222ABU onsemi TRANS NPN 40V 1A TO92-3
PN2222ABU Images
PN2222ABU Images
PN2222ABU
  • Manufacturer: onsemi (ON)
  • Category: Discrete Semiconductor Products~Transistors - Bipolar (BJT) - Single Package/Case: TO-226-3, TO-92-3 (TO-226AA)
  • Description: TRANS NPN 40V 1A TO92-3
  • COMPETITIVE PRICE and DELIVERY TIME
  • Order with confidence, there are no lead times for in-stock products.
Quickly Quote for You to Meet Your Target Price, Support Small Order Quantity with Fast Quick Delivery.
Download Datasheet (PDF)
PN2222ABU Datasheet
ELECTRONIC COMPONENTS, CHOOSE NHE ELECTRONICS
PN2222ABU Specifications:
  • MfrPart.: PN2222ABU
  • Mfr: onsemi
  • Description: TRANS NPN 40V 1A TO92-3
  • Product Category: Discrete Semiconductor Products~Transistors - Bipolar (BJT) - Single
  • Package: Bulk
  • Series: -
  • PartStatus: Active
  • TransistorType: NPN
  • Current-Collector(Ic)(Max): 1 A
  • Voltage-CollectorEmitterBreakdown(Max): 40 V
  • VceSaturation(Max)@IbIc: 1V @ 50mA, 500mA
  • Current-CollectorCutoff(Max): 10nA (ICBO)
  • DCCurrentGain(hFE)(Min)@IcVce: 100 @ 150mA, 10V
  • Power-Max: 625 mW
  • Frequency-Transition: 300MHz
  • OperatingTemperature: -55°C ~ 150°C (TJ)
  • MountingType: Through Hole
  • Package/Case: TO-226-3, TO-92-3 (TO-226AA)
  • PN2222ABU onsemi (ON), TRANS NPN 40V 1A TO92-3, Discrete Semiconductor Products~Transistors - Bipolar (BJT) - Single
