NZT753 Images
- Manufacturer: onsemi (ON)
- Category: Discrete Semiconductor Products~Transistors - Bipolar (BJT) - Single Package/Case: TO-261-4, TO-261AA
- Description: TRANS PNP 100V 4A SOT223-4
- COMPETITIVE PRICE and DELIVERY TIME
- Order with confidence, there are no lead times for in-stock products.
Download Datasheet (PDF)
NZT753 Specifications:
- MfrPart.: NZT753
- Mfr: onsemi
- Description: TRANS PNP 100V 4A SOT223-4
- Product Category: Discrete Semiconductor Products~Transistors - Bipolar (BJT) - Single
- Package: Tape & Reel (TR),Cut Tape (CT)
- Series: -
- PartStatus: Active
- TransistorType: PNP
- Current-Collector(Ic)(Max): 4 A
- Voltage-CollectorEmitterBreakdown(Max): 100 V
- VceSaturation(Max)@IbIc: 300mV @ 50mA, 1A
- Current-CollectorCutoff(Max): 100nA (ICBO)
- DCCurrentGain(hFE)(Min)@IcVce: 100 @ 500mA, 2V
- Power-Max: 1.2 W
- Frequency-Transition: 75MHz
- OperatingTemperature: -55°C ~ 150°C (TJ)
- MountingType: Surface Mount
- Package/Case: TO-261-4, TO-261AA
- NZT753 onsemi (ON), TRANS PNP 100V 4A SOT223-4, Discrete Semiconductor Products~Transistors - Bipolar (BJT) - Single
