NXH80T120L2Q0SG Images
- Manufacturer: onsemi (ON)
- Category: Discrete Semiconductor Products~Transistors - IGBTs - Modules Package/Case: Module
- Description: IGBT MODULE 1200V 65A 146W PIM20
- COMPETITIVE PRICE and DELIVERY TIME
- Order with confidence, there are no lead times for in-stock products.
Download Datasheet (PDF)
NXH80T120L2Q0SG Specifications:
- MfrPart.: NXH80T120L2Q0SG
- Mfr: onsemi
- Description: IGBT MODULE 1200V 65A 146W PIM20
- Product Category: Discrete Semiconductor Products~Transistors - IGBTs - Modules
- Package: Tray
- Series: -
- PartStatus: Active
- IGBTType: -
- Configuration: T-Type
- Voltage-CollectorEmitterBreakdown(Max): 1200 V
- Current-Collector(Ic)(Max): 65 A
- Power-Max: 146 W
- Vce(on)(Max)@VgeIc: 2.8V @ 15V, 80A
- Current-CollectorCutoff(Max): 100 µA
- InputCapacitance(Cies)@Vce: 1.99 nF @ 20 V
- Input: Standard
- NTCThermistor: Yes
- OperatingTemperature: -40°C ~ 150°C (TJ)
- MountingType: Through Hole
- Package/Case: Module
- NXH80T120L2Q0SG onsemi (ON), IGBT MODULE 1200V 65A 146W PIM20, Discrete Semiconductor Products~Transistors - IGBTs - Modules
