NXH40T120L3Q1SG Images
- Manufacturer: onsemi (ON)
- Category: Discrete Semiconductor Products~Transistors - IGBTs - Modules Package/Case: Module
- Description: IGBT MODULE SUNGROW 20KW Q1PACK
- COMPETITIVE PRICE and DELIVERY TIME
- Order with confidence, there are no lead times for in-stock products.
Download Datasheet (PDF)
NXH40T120L3Q1SG Specifications:
- MfrPart.: NXH40T120L3Q1SG
- Mfr: onsemi
- Description: IGBT MODULE SUNGROW 20KW Q1PACK
- Product Category: Discrete Semiconductor Products~Transistors - IGBTs - Modules
- Package: Tray
- Series: -
- PartStatus: Active
- IGBTType: -
- Configuration: Three Phase
- Voltage-CollectorEmitterBreakdown(Max): -
- Current-Collector(Ic)(Max): -
- Power-Max: -
- Vce(on)(Max)@VgeIc: 2.2V @ 15V, 40A
- Current-CollectorCutoff(Max): 400 µA
- InputCapacitance(Cies)@Vce: -
- Input: Three Phase Bridge Rectifier
- NTCThermistor: Yes
- OperatingTemperature: -40°C ~ 75°C (TJ)
- MountingType: Chassis Mount
- Package/Case: Module
- NXH40T120L3Q1SG onsemi (ON), IGBT MODULE SUNGROW 20KW Q1PACK, Discrete Semiconductor Products~Transistors - IGBTs - Modules
