NXH35C120L2C2ESG Images
- Manufacturer: onsemi (ON)
- Category: Discrete Semiconductor Products~Transistors - IGBTs - Modules Package/Case: 26-PowerDIP Module (1.199, 47.20mm)
- Description: IGBT MODULE, CIB 1200 V, 35 A IG
- COMPETITIVE PRICE and DELIVERY TIME
- Order with confidence, there are no lead times for in-stock products.
Download Datasheet (PDF)
NXH35C120L2C2ESG Specifications:
- MfrPart.: NXH35C120L2C2ESG
- Mfr: onsemi
- Description: IGBT MODULE, CIB 1200 V, 35 A IG
- Product Category: Discrete Semiconductor Products~Transistors - IGBTs - Modules
- Package: Tube
- Series: -
- PartStatus: Active
- IGBTType: -
- Configuration: Three Phase Inverter with Brake
- Voltage-CollectorEmitterBreakdown(Max): 1200 V
- Current-Collector(Ic)(Max): 35 A
- Power-Max: 20 mW
- Vce(on)(Max)@VgeIc: 2.4V @ 15V, 35A
- Current-CollectorCutoff(Max): 250 µA
- InputCapacitance(Cies)@Vce: 8.333 nF @ 20 V
- Input: Three Phase Bridge Rectifier
- NTCThermistor: Yes
- OperatingTemperature: -40°C ~ 150°C (TJ)
- MountingType: Through Hole
- Package/Case: 26-PowerDIP Module (1.199, 47.20mm)
- NXH35C120L2C2ESG onsemi (ON), IGBT MODULE, CIB 1200 V, 35 A IG, Discrete Semiconductor Products~Transistors - IGBTs - Modules
NXH35C120L2C2ESG, onsemi authentic parts in stock from onsemi (ON) authorized distributors, order today, can ship immediately.
