NXH350N100H4Q2F2P1G Images
- Manufacturer: onsemi (ON)
- Category: Discrete Semiconductor Products~Transistors - IGBTs - Modules Package/Case: Module
- Description: IC PWR MODULE 1000V 350A PIM42
- COMPETITIVE PRICE and DELIVERY TIME
- Order with confidence, there are no lead times for in-stock products.
Download Datasheet (PDF)
NXH350N100H4Q2F2P1G Specifications:
- MfrPart.: NXH350N100H4Q2F2P1G
- Mfr: onsemi
- Description: IC PWR MODULE 1000V 350A PIM42
- Product Category: Discrete Semiconductor Products~Transistors - IGBTs - Modules
- Package: Tray
- Series: -
- PartStatus: Active
- IGBTType: Trench Field Stop
- Configuration: Three Level Inverter
- Voltage-CollectorEmitterBreakdown(Max): 1000 V
- Current-Collector(Ic)(Max): 303 A
- Power-Max: 276 W
- Vce(on)(Max)@VgeIc: 2.3V @ 15V, 375A
- Current-CollectorCutoff(Max): 1 mA
- InputCapacitance(Cies)@Vce: 24.146 nF @ 20 V
- Input: Standard
- NTCThermistor: Yes
- OperatingTemperature: -40°C ~ 150°C (TJ)
- MountingType: Chassis Mount
- Package/Case: Module
- NXH350N100H4Q2F2P1G onsemi (ON), IC PWR MODULE 1000V 350A PIM42, Discrete Semiconductor Products~Transistors - IGBTs - Modules
