NXH100B120H3Q0PTG Images
- Manufacturer: onsemi (ON)
- Category: Discrete Semiconductor Products~Transistors - IGBTs - Modules Package/Case: Module
- Description: IGBT MODULE 1200V 50A 186W 22PIM
- COMPETITIVE PRICE and DELIVERY TIME
- Order with confidence, there are no lead times for in-stock products.
Download Datasheet (PDF)
NXH100B120H3Q0PTG Specifications:
- MfrPart.: NXH100B120H3Q0PTG
- Mfr: onsemi
- Description: IGBT MODULE 1200V 50A 186W 22PIM
- Product Category: Discrete Semiconductor Products~Transistors - IGBTs - Modules
- Package: Tray
- Series: -
- PartStatus: Active
- IGBTType: Trench Field Stop
- Configuration: 2 Independent
- Voltage-CollectorEmitterBreakdown(Max): 1200 V
- Current-Collector(Ic)(Max): 50 A
- Power-Max: 186 W
- Vce(on)(Max)@VgeIc: 2.3V @ 15V, 50A
- Current-CollectorCutoff(Max): 200 µA
- InputCapacitance(Cies)@Vce: 9.075 nF @ 20 V
- Input: Standard
- NTCThermistor: No
- OperatingTemperature: -40°C ~ 150°C (TJ)
- MountingType: Chassis Mount
- Package/Case: Module
