NVTR01P02LT1G onsemi MOSFET P-CH 20V 1.3A SOT23-3
NVTR01P02LT1G Images
NVTR01P02LT1G Images
  • Manufacturer: onsemi (ON)
  • Category: Discrete Semiconductor Products~Transistors - FETs, MOSFETs - Single SupplierDevicePackage: SOT-23-3 (TO-236)
  • Description: MOSFET P-CH 20V 1.3A SOT23-3
  • COMPETITIVE PRICE and DELIVERY TIME
  • Order with confidence, there are no lead times for in-stock products.
Quickly Quote for You to Meet Your Target Price, Support Small Order Quantity with Fast Quick Delivery.
Download Datasheet (PDF)
NVTR01P02LT1G Datasheet
ELECTRONIC COMPONENTS, CHOOSE NHE ELECTRONICS
NVTR01P02LT1G Specifications:
  • MfrPart.: NVTR01P02LT1G
  • Mfr: onsemi
  • Description: MOSFET P-CH 20V 1.3A SOT23-3
  • Product Category: Discrete Semiconductor Products~Transistors - FETs, MOSFETs - Single
  • Package: Tape & Reel (TR),Cut Tape (CT)
  • Series: -
  • PartStatus: Active
  • FETType: P-Channel
  • Technology: MOSFET (Metal Oxide)
  • DraintoSourceVoltage(Vdss): 20 V
  • Current-ContinuousDrain(Id)@25°C: 1.3A (Ta)
  • DriveVoltage(MaxRdsOnMinRdsOn): 2.5V, 4.5V
  • RdsOn(Max)@IdVgs: 220mOhm @ 750mA, 4.5V
  • Vgs(th)(Max)@Id: 1.25V @ 250µA
  • GateCharge(Qg)(Max)@Vgs: 3.1 nC @ 4 V
  • Vgs(Max): ±12V
  • InputCapacitance(Ciss)(Max)@Vds: 225 pF @ 5 V
  • FETFeature: -
  • PowerDissipation(Max): 400mW (Ta)
  • OperatingTemperature: -
  • MountingType: Surface Mount
  • SupplierDevicePackage: SOT-23-3 (TO-236)
  • NVTR01P02LT1G onsemi (ON), MOSFET P-CH 20V 1.3A SOT23-3, Discrete Semiconductor Products~Transistors - FETs, MOSFETs - Single
NVTR01P02LT1G, onsemi authentic parts in stock from onsemi (ON) authorized distributors, order today, can ship immediately.
