NVTFS6H854NLWFTAG Images
- Manufacturer: onsemi (ON)
- Category: Discrete Semiconductor Products~Transistors - FETs, MOSFETs - Single SupplierDevicePackage: 8-WDFN (3.3x3.3)
- Description: MOSFET N-CH 80V 10A/41A 8WDFN
- COMPETITIVE PRICE and DELIVERY TIME
- Order with confidence, there are no lead times for in-stock products.
Download Datasheet (PDF)
NVTFS6H854NLWFTAG Specifications:
- MfrPart.: NVTFS6H854NLWFTAG
- Mfr: onsemi
- Description: MOSFET N-CH 80V 10A/41A 8WDFN
- Product Category: Discrete Semiconductor Products~Transistors - FETs, MOSFETs - Single
- Package: Tape & Reel (TR)
- Series: Automotive, AEC-Q101
- PartStatus: Active
- FETType: N-Channel
- Technology: MOSFET (Metal Oxide)
- DraintoSourceVoltage(Vdss): 80 V
- Current-ContinuousDrain(Id)@25°C: 10A (Ta), 41A (Tc)
- DriveVoltage(MaxRdsOnMinRdsOn): 4.5V, 10V
- RdsOn(Max)@IdVgs: 13.4mOhm @ 10A, 10V
- Vgs(th)(Max)@Id: 2V @ 45µA
- GateCharge(Qg)(Max)@Vgs: 17 nC @ 10 V
- Vgs(Max): ±20V
- InputCapacitance(Ciss)(Max)@Vds: 902 pF @ 40 V
- FETFeature: -
- PowerDissipation(Max): 3.2W (Ta), 54W (Tc)
- OperatingTemperature: -55°C ~ 175°C (TJ)
- MountingType: Surface Mount
- SupplierDevicePackage: 8-WDFN (3.3x3.3)
- NVTFS6H854NLWFTAG onsemi (ON), MOSFET N-CH 80V 10A/41A 8WDFN, Discrete Semiconductor Products~Transistors - FETs, MOSFETs - Single
NVTFS6H854NLWFTAG, onsemi authentic parts in stock from onsemi (ON) authorized distributors, order today, can ship immediately.
