NVTFS4C25NTAG Images
- Manufacturer: onsemi (ON)
- Category: Discrete Semiconductor Products~Transistors - FETs, MOSFETs - Single SupplierDevicePackage: 8-WDFN (3.3x3.3)
- Description: MOSFET N-CH 30V 10.1A/22.1A 8DFN
- COMPETITIVE PRICE and DELIVERY TIME
- Order with confidence, there are no lead times for in-stock products.
Download Datasheet (PDF)
NVTFS4C25NTAG Specifications:
- MfrPart.: NVTFS4C25NTAG
- Mfr: onsemi
- Description: MOSFET N-CH 30V 10.1A/22.1A 8DFN
- Product Category: Discrete Semiconductor Products~Transistors - FETs, MOSFETs - Single
- Package: Tape & Reel (TR),Cut Tape (CT)
- Series: -
- PartStatus: Active
- FETType: N-Channel
- Technology: MOSFET (Metal Oxide)
- DraintoSourceVoltage(Vdss): 30 V
- Current-ContinuousDrain(Id)@25°C: 10.1A (Ta), 22.1A (Tc)
- DriveVoltage(MaxRdsOnMinRdsOn): 4.5V, 10V
- RdsOn(Max)@IdVgs: 17mOhm @ 10A, 10V
- Vgs(th)(Max)@Id: 2.2V @ 250µA
- GateCharge(Qg)(Max)@Vgs: 10.3 nC @ 10 V
- Vgs(Max): ±20V
- InputCapacitance(Ciss)(Max)@Vds: 500 pF @ 15 V
- FETFeature: -
- PowerDissipation(Max): 3W (Ta), 14.3W (Tc)
- OperatingTemperature: -55°C ~ 175°C (TJ)
- MountingType: Surface Mount
- SupplierDevicePackage: 8-WDFN (3.3x3.3)
- NVTFS4C25NTAG onsemi (ON), MOSFET N-CH 30V 10.1A/22.1A 8DFN, Discrete Semiconductor Products~Transistors - FETs, MOSFETs - Single
NVTFS4C25NTAG, onsemi authentic parts in stock from onsemi (ON) authorized distributors, order today, can ship immediately.
