NVTFS4C02NTAG Images
- Manufacturer: onsemi (ON)
- Category: Discrete Semiconductor Products~Transistors - FETs, MOSFETs - Single SupplierDevicePackage: Surface Mount
- Description: MOSFET - SINGLE N-CHANNEL POWER
- COMPETITIVE PRICE and DELIVERY TIME
- Order with confidence, there are no lead times for in-stock products.
Download Datasheet (PDF)
NVTFS4C02NTAG Specifications:
- MfrPart.: NVTFS4C02NTAG
- Mfr: onsemi
- Description: MOSFET - SINGLE N-CHANNEL POWER
- Product Category: Discrete Semiconductor Products~Transistors - FETs, MOSFETs - Single
- Package: 1
- Series: Tape & Reel (TR),Cut Tape (CT)
- PartStatus: Automotive, AEC-Q101
- FETType: Active
- Technology: N-Channel
- DraintoSourceVoltage(Vdss): MOSFET (Metal Oxide)
- Current-ContinuousDrain(Id)@25°C: 30 V
- DriveVoltage(MaxRdsOnMinRdsOn): 28.3A (Ta), 162A (Tc)
- RdsOn(Max)@IdVgs: 4.5V, 10V
- Vgs(th)(Max)@Id: 2.25mOhm @ 20A, 10V
- GateCharge(Qg)(Max)@Vgs: 2.2V @ 250µA
- Vgs(Max): 20 nC @ 4.5 V
- InputCapacitance(Ciss)(Max)@Vds: ±20V
- FETFeature: 2980 pF @ 15 V
- PowerDissipation(Max): -
- OperatingTemperature: 3.2W (Ta), 107W (Tc)
- MountingType: -55°C ~ 175°C (TJ)
- SupplierDevicePackage: Surface Mount
- NVTFS4C02NTAG onsemi (ON), MOSFET - SINGLE N-CHANNEL POWER, Discrete Semiconductor Products~Transistors - FETs, MOSFETs - Single
