NVTFS010N10MCLTAG Images
- Manufacturer: onsemi (ON)
- Category: Discrete Semiconductor Products~Transistors - FETs, MOSFETs - Single SupplierDevicePackage: 8-WDFN (3.3x3.3)
- Description: MOSFET N-CH 100V 11.7A/57.8 8DFN
- COMPETITIVE PRICE and DELIVERY TIME
- Order with confidence, there are no lead times for in-stock products.
Download Datasheet (PDF)
NVTFS010N10MCLTAG Specifications:
- MfrPart.: NVTFS010N10MCLTAG
- Mfr: onsemi
- Description: MOSFET N-CH 100V 11.7A/57.8 8DFN
- Product Category: Discrete Semiconductor Products~Transistors - FETs, MOSFETs - Single
- Package: Tape & Reel (TR),Cut Tape (CT)
- Series: Automotive, AEC-Q101
- PartStatus: Active
- FETType: N-Channel
- Technology: MOSFET (Metal Oxide)
- DraintoSourceVoltage(Vdss): 100 V
- Current-ContinuousDrain(Id)@25°C: 11.7A (Ta), 57.8 (Tc)
- DriveVoltage(MaxRdsOnMinRdsOn): 4.5V, 10V
- RdsOn(Max)@IdVgs: 10.6mOhm @ 15A, 10V
- Vgs(th)(Max)@Id: 3V @ 85µA
- GateCharge(Qg)(Max)@Vgs: 30 nC @ 10 V
- Vgs(Max): ±20V
- InputCapacitance(Ciss)(Max)@Vds: 2150 pF @ 50 V
- FETFeature: -
- PowerDissipation(Max): 3.2W (Ta), 77.8W (Tc)
- OperatingTemperature: -55°C ~ 175°C (TJ)
- MountingType: Surface Mount
- SupplierDevicePackage: 8-WDFN (3.3x3.3)
- NVTFS010N10MCLTAG onsemi (ON), MOSFET N-CH 100V 11.7A/57.8 8DFN, Discrete Semiconductor Products~Transistors - FETs, MOSFETs - Single
