NVMYS2D1N04CLTWG Images
- Manufacturer: onsemi (ON)
- Category: Discrete Semiconductor Products~Transistors - FETs, MOSFETs - Single SupplierDevicePackage: 4-LFPAK
- Description: MOSFET N-CH 40V 29A/132A LFPAK4
- COMPETITIVE PRICE and DELIVERY TIME
- Order with confidence, there are no lead times for in-stock products.
Download Datasheet (PDF)
NVMYS2D1N04CLTWG Specifications:
- MfrPart.: NVMYS2D1N04CLTWG
- Mfr: onsemi
- Description: MOSFET N-CH 40V 29A/132A LFPAK4
- Product Category: Discrete Semiconductor Products~Transistors - FETs, MOSFETs - Single
- Package: Tape & Reel (TR)
- Series: Automotive, AEC-Q101
- PartStatus: Active
- FETType: N-Channel
- Technology: MOSFET (Metal Oxide)
- DraintoSourceVoltage(Vdss): 40 V
- Current-ContinuousDrain(Id)@25°C: 29A (Ta), 132A (Tc)
- DriveVoltage(MaxRdsOnMinRdsOn): 4.5V, 10V
- RdsOn(Max)@IdVgs: 2.5mOhm @ 50A, 10V
- Vgs(th)(Max)@Id: 2V @ 90µA
- GateCharge(Qg)(Max)@Vgs: 50 nC @ 10 V
- Vgs(Max): ±20V
- InputCapacitance(Ciss)(Max)@Vds: 3100 pF @ 25 V
- FETFeature: -
- PowerDissipation(Max): 3.9W (Ta), 83W (Tc)
- OperatingTemperature: -55°C ~ 175°C (TJ)
- MountingType: Surface Mount
- SupplierDevicePackage: 4-LFPAK
- NVMYS2D1N04CLTWG onsemi (ON), MOSFET N-CH 40V 29A/132A LFPAK4, Discrete Semiconductor Products~Transistors - FETs, MOSFETs - Single
