NVMTS4D3N15MC Images
- Manufacturer: onsemi (ON)
- Category: Discrete Semiconductor Products~Transistors - FETs, MOSFETs - Single SupplierDevicePackage: 8-DFNW (8.3x8.4)
- Description: SINGLE N-CHANNEL POWER MOSFET 00
- COMPETITIVE PRICE and DELIVERY TIME
- Order with confidence, there are no lead times for in-stock products.
Download Datasheet (PDF)
NVMTS4D3N15MC Specifications:
- MfrPart.: NVMTS4D3N15MC
- Mfr: onsemi
- Description: SINGLE N-CHANNEL POWER MOSFET 00
- Product Category: Discrete Semiconductor Products~Transistors - FETs, MOSFETs - Single
- Package: Tape & Reel (TR),Cut Tape (CT)
- Series: -
- PartStatus: Active
- FETType: N-Channel
- Technology: MOSFET (Metal Oxide)
- DraintoSourceVoltage(Vdss): 150 V
- Current-ContinuousDrain(Id)@25°C: 21A (Ta), 165A (Tc)
- DriveVoltage(MaxRdsOnMinRdsOn): 10V
- RdsOn(Max)@IdVgs: 4.45mOhm @ 95A, 10V
- Vgs(th)(Max)@Id: 4.5V @ 521µA
- GateCharge(Qg)(Max)@Vgs: 79 nC @ 10 V
- Vgs(Max): ±20V
- InputCapacitance(Ciss)(Max)@Vds: 6514 pF @ 75 V
- FETFeature: -
- PowerDissipation(Max): 5W (Ta), 292W (Tc)
- OperatingTemperature: -55°C ~ 175°C (TJ)
- MountingType: Surface Mount
- SupplierDevicePackage: 8-DFNW (8.3x8.4)
- NVMTS4D3N15MC onsemi (ON), SINGLE N-CHANNEL POWER MOSFET 00, Discrete Semiconductor Products~Transistors - FETs, MOSFETs - Single
