NVMFSC0D9N04CL Images
- Manufacturer: onsemi (ON)
- Category: Discrete Semiconductor Products~Transistors - FETs, MOSFETs - Single SupplierDevicePackage: 8-DFN (5.1x6.15)
- Description: MOSFET N-CH 40V 50A/316A 8DFN
- COMPETITIVE PRICE and DELIVERY TIME
- Order with confidence, there are no lead times for in-stock products.
Download Datasheet (PDF)
NVMFSC0D9N04CL Specifications:
- MfrPart.: NVMFSC0D9N04CL
- Mfr: onsemi
- Description: MOSFET N-CH 40V 50A/316A 8DFN
- Product Category: Discrete Semiconductor Products~Transistors - FETs, MOSFETs - Single
- Package: Tape & Reel (TR),Cut Tape (CT)
- Series: Automotive, AEC-Q101
- PartStatus: Active
- FETType: N-Channel
- Technology: MOSFET (Metal Oxide)
- DraintoSourceVoltage(Vdss): 40 V
- Current-ContinuousDrain(Id)@25°C: 50A (Ta), 316A (Tc)
- DriveVoltage(MaxRdsOnMinRdsOn): 10V
- RdsOn(Max)@IdVgs: 870µOhm @ 50A, 10V
- Vgs(th)(Max)@Id: 3.5V @ 250µA
- GateCharge(Qg)(Max)@Vgs: 86 nC @ 10 V
- Vgs(Max): ±20V
- InputCapacitance(Ciss)(Max)@Vds: 6100 pF @ 25 V
- FETFeature: -
- PowerDissipation(Max): 4.1W (Ta), 166W (Tc)
- OperatingTemperature: -55°C ~ 175°C (TJ)
- MountingType: Surface Mount
- SupplierDevicePackage: 8-DFN (5.1x6.15)
- NVMFSC0D9N04CL onsemi (ON), MOSFET N-CH 40V 50A/316A 8DFN, Discrete Semiconductor Products~Transistors - FETs, MOSFETs - Single
NVMFSC0D9N04CL, onsemi authentic parts in stock from onsemi (ON) authorized distributors, order today, can ship immediately.
