NVMFS5C680NLWFT1G Images
- Manufacturer: onsemi (ON)
- Category: Discrete Semiconductor Products~Transistors - FETs, MOSFETs - Single SupplierDevicePackage: 5-DFN (5x6) (8-SOFL)
- Description: MOSFET N-CH 60V 8.1A/21A 5DFN
- COMPETITIVE PRICE and DELIVERY TIME
- Order with confidence, there are no lead times for in-stock products.
Download Datasheet (PDF)
NVMFS5C680NLWFT1G Specifications:
- MfrPart.: NVMFS5C680NLWFT1G
- Mfr: onsemi
- Description: MOSFET N-CH 60V 8.1A/21A 5DFN
- Product Category: Discrete Semiconductor Products~Transistors - FETs, MOSFETs - Single
- Package: Bulk
- Series: Automotive, AEC-Q101
- PartStatus: Active
- FETType: N-Channel
- Technology: MOSFET (Metal Oxide)
- DraintoSourceVoltage(Vdss): 60 V
- Current-ContinuousDrain(Id)@25°C: 8.1A (Ta), 21A (Tc)
- DriveVoltage(MaxRdsOnMinRdsOn): 4.5V, 10V
- RdsOn(Max)@IdVgs: 27.5mOhm @ 7.5A, 10V
- Vgs(th)(Max)@Id: 2.2V @ 13µA
- GateCharge(Qg)(Max)@Vgs: 5.8 nC @ 10 V
- Vgs(Max): ±20V
- InputCapacitance(Ciss)(Max)@Vds: 330 pF @ 25 V
- FETFeature: -
- PowerDissipation(Max): 3.4W (Ta), 24W (Tc)
- OperatingTemperature: -55°C ~ 175°C (TJ)
- MountingType: Surface Mount
- SupplierDevicePackage: 5-DFN (5x6) (8-SOFL)
- NVMFS5C680NLWFT1G onsemi (ON), MOSFET N-CH 60V 8.1A/21A 5DFN, Discrete Semiconductor Products~Transistors - FETs, MOSFETs - Single
NVMFS5C680NLWFT1G, onsemi authentic parts in stock from onsemi (ON) authorized distributors, order today, can ship immediately.
