NVMFS3D6N10MCLT1G Images
- Manufacturer: onsemi (ON)
- Category: Discrete Semiconductor Products~Transistors - FETs, MOSFETs - Single SupplierDevicePackage: 5-DFN (5x6) (8-SOFL)
- Description: MOSFET N-CH 100V 20A/132A 5DFN
- COMPETITIVE PRICE and DELIVERY TIME
- Order with confidence, there are no lead times for in-stock products.
Download Datasheet (PDF)
NVMFS3D6N10MCLT1G Specifications:
- MfrPart.: NVMFS3D6N10MCLT1G
- Mfr: onsemi
- Description: MOSFET N-CH 100V 20A/132A 5DFN
- Product Category: Discrete Semiconductor Products~Transistors - FETs, MOSFETs - Single
- Package: Tape & Reel (TR),Cut Tape (CT)
- Series: Automotive, AEC-Q101
- PartStatus: Active
- FETType: N-Channel
- Technology: MOSFET (Metal Oxide)
- DraintoSourceVoltage(Vdss): 100 V
- Current-ContinuousDrain(Id)@25°C: 20A (Ta), 132A (Tc)
- DriveVoltage(MaxRdsOnMinRdsOn): 4.5V, 10V
- RdsOn(Max)@IdVgs: 3.6mOhm @ 48A, 10V
- Vgs(th)(Max)@Id: 3V @ 270µA
- GateCharge(Qg)(Max)@Vgs: 60 V @ 10 V
- Vgs(Max): ±20V
- InputCapacitance(Ciss)(Max)@Vds: 4411 pF @ 50 V
- FETFeature: -
- PowerDissipation(Max): 3.2W (Ta), 139W (Tc)
- OperatingTemperature: -55°C ~ 175°C (TJ)
- MountingType: Surface Mount
- SupplierDevicePackage: 5-DFN (5x6) (8-SOFL)
- NVMFS3D6N10MCLT1G onsemi (ON), MOSFET N-CH 100V 20A/132A 5DFN, Discrete Semiconductor Products~Transistors - FETs, MOSFETs - Single
NVMFS3D6N10MCLT1G, onsemi authentic parts in stock from onsemi (ON) authorized distributors, order today, can ship immediately.
