NVMFD6H852NLWFT1G Images
- Manufacturer: onsemi (ON)
- Category: Discrete Semiconductor Products~Transistors - FETs, MOSFETs - Single SupplierDevicePackage: 8-DFN (5x6) Dual Flag (SO8FL-Dual-Asymmetrical)
- Description: MOSFET N-CH 80V 7A/25A 8DFN DL
- COMPETITIVE PRICE and DELIVERY TIME
- Order with confidence, there are no lead times for in-stock products.
Download Datasheet (PDF)
NVMFD6H852NLWFT1G Specifications:
- MfrPart.: NVMFD6H852NLWFT1G
- Mfr: onsemi
- Description: MOSFET N-CH 80V 7A/25A 8DFN DL
- Product Category: Discrete Semiconductor Products~Transistors - FETs, MOSFETs - Single
- Package: Tape & Reel (TR),Cut Tape (CT)
- Series: Automotive, AEC-Q101
- PartStatus: Active
- FETType: N-Channel
- Technology: MOSFET (Metal Oxide)
- DraintoSourceVoltage(Vdss): 80 V
- Current-ContinuousDrain(Id)@25°C: 7A (Ta), 25A (Tc)
- DriveVoltage(MaxRdsOnMinRdsOn): 4.5V, 10V
- RdsOn(Max)@IdVgs: 25.5mOhm @ 10A, 10V
- Vgs(th)(Max)@Id: 2V @ 26µA
- GateCharge(Qg)(Max)@Vgs: 10 nC @ 10 V
- Vgs(Max): ±20V
- InputCapacitance(Ciss)(Max)@Vds: 521 pF @ 40 V
- FETFeature: -
- PowerDissipation(Max): 3.2W (Ta), 38W (Tc)
- OperatingTemperature: -55°C ~ 175°C (TJ)
- MountingType: Surface Mount
- SupplierDevicePackage: 8-DFN (5x6) Dual Flag (SO8FL-Dual-Asymmetrical)
- NVMFD6H852NLWFT1G onsemi (ON), MOSFET N-CH 80V 7A/25A 8DFN DL, Discrete Semiconductor Products~Transistors - FETs, MOSFETs - Single
NVMFD6H852NLWFT1G, onsemi authentic parts in stock from onsemi (ON) authorized distributors, order today, can ship immediately.
