NVHL080N120SC1A Images
- Manufacturer: onsemi (ON)
- Category: Discrete Semiconductor Products~Transistors - FETs, MOSFETs - Single SupplierDevicePackage: TO-247-3
- Description: TRANS SJT N-CH 1200V 31A TO247-3
- COMPETITIVE PRICE and DELIVERY TIME
- Order with confidence, there are no lead times for in-stock products.
Download Datasheet (PDF)
NVHL080N120SC1A Specifications:
- MfrPart.: NVHL080N120SC1A
- Mfr: onsemi
- Description: TRANS SJT N-CH 1200V 31A TO247-3
- Product Category: Discrete Semiconductor Products~Transistors - FETs, MOSFETs - Single
- Package: Tube
- Series: Automotive, AEC-Q101
- PartStatus: Active
- FETType: N-Channel
- Technology: SiC (Silicon Carbide Junction Transistor)
- DraintoSourceVoltage(Vdss): 1200 V
- Current-ContinuousDrain(Id)@25°C: 31A (Tc)
- DriveVoltage(MaxRdsOnMinRdsOn): 20V
- RdsOn(Max)@IdVgs: 110mOhm @ 20A, 20V
- Vgs(th)(Max)@Id: 4.3V @ 5mA
- GateCharge(Qg)(Max)@Vgs: 56 nC @ 20 V
- Vgs(Max): +25, -15V
- InputCapacitance(Ciss)(Max)@Vds: 1670 pF @ 800 V
- FETFeature: -
- PowerDissipation(Max): 178W (Tc)
- OperatingTemperature: -55°C ~ 175°C (TJ)
- MountingType: Through Hole
- SupplierDevicePackage: TO-247-3
- NVHL080N120SC1A onsemi (ON), TRANS SJT N-CH 1200V 31A TO247-3, Discrete Semiconductor Products~Transistors - FETs, MOSFETs - Single
NVHL080N120SC1A, onsemi authentic parts in stock from onsemi (ON) authorized distributors, order today, can ship immediately.
