NVHL060N090SC1 Images
- Manufacturer: onsemi (ON)
- Category: Discrete Semiconductor Products~Transistors - FETs, MOSFETs - Single SupplierDevicePackage: TO-247-3
- Description: TRANS SJT N-CH 900V 46A TO247-3
- COMPETITIVE PRICE and DELIVERY TIME
- Order with confidence, there are no lead times for in-stock products.
Download Datasheet (PDF)
NVHL060N090SC1 Specifications:
- MfrPart.: NVHL060N090SC1
- Mfr: onsemi
- Description: TRANS SJT N-CH 900V 46A TO247-3
- Product Category: Discrete Semiconductor Products~Transistors - FETs, MOSFETs - Single
- Package: Tube
- Series: Automotive, AEC-Q101
- PartStatus: Active
- FETType: N-Channel
- Technology: SiC (Silicon Carbide Junction Transistor)
- DraintoSourceVoltage(Vdss): 900 V
- Current-ContinuousDrain(Id)@25°C: 46A (Tc)
- DriveVoltage(MaxRdsOnMinRdsOn): 15V
- RdsOn(Max)@IdVgs: 84mOhm @ 20A, 15V
- Vgs(th)(Max)@Id: 4.3V @ 5mA
- GateCharge(Qg)(Max)@Vgs: 87 nC @ 15 V
- Vgs(Max): +19V, -10V
- InputCapacitance(Ciss)(Max)@Vds: 1770 pF @ 450 V
- FETFeature: -
- PowerDissipation(Max): 221W (Tc)
- OperatingTemperature: -55°C ~ 175°C (TJ)
- MountingType: Through Hole
- SupplierDevicePackage: TO-247-3
- NVHL060N090SC1 onsemi (ON), TRANS SJT N-CH 900V 46A TO247-3, Discrete Semiconductor Products~Transistors - FETs, MOSFETs - Single
