NVH4L020N120SC1 Images
- Manufacturer: onsemi (ON)
- Category: Discrete Semiconductor Products~Transistors - FETs, MOSFETs - Single SupplierDevicePackage: TO-247-4L
- Description: TRANS SJT N-CH 1200V 102A TO247
- COMPETITIVE PRICE and DELIVERY TIME
- Order with confidence, there are no lead times for in-stock products.
Download Datasheet (PDF)
NVH4L020N120SC1 Specifications:
- MfrPart.: NVH4L020N120SC1
- Mfr: onsemi
- Description: TRANS SJT N-CH 1200V 102A TO247
- Product Category: Discrete Semiconductor Products~Transistors - FETs, MOSFETs - Single
- Package: Tube
- Series: Automotive, AEC-Q101
- PartStatus: Active
- FETType: N-Channel
- Technology: SiC (Silicon Carbide Junction Transistor)
- DraintoSourceVoltage(Vdss): 1200 V
- Current-ContinuousDrain(Id)@25°C: 102A (Tc)
- DriveVoltage(MaxRdsOnMinRdsOn): 20V
- RdsOn(Max)@IdVgs: 28mOhm @ 60A, 20V
- Vgs(th)(Max)@Id: 4.3V @ 20mA
- GateCharge(Qg)(Max)@Vgs: 220 nC @ 20 V
- Vgs(Max): +25V, -15V
- InputCapacitance(Ciss)(Max)@Vds: 2943 pF @ 800 V
- FETFeature: -
- PowerDissipation(Max): 510W (Tc)
- OperatingTemperature: -55°C ~ 175°C (TJ)
- MountingType: Through Hole
- SupplierDevicePackage: TO-247-4L
- NVH4L020N120SC1 onsemi (ON), TRANS SJT N-CH 1200V 102A TO247, Discrete Semiconductor Products~Transistors - FETs, MOSFETs - Single
