NVF6P02T3G Images
- Manufacturer: onsemi (ON)
- Category: Discrete Semiconductor Products~Transistors - FETs, MOSFETs - Single SupplierDevicePackage: SOT-223 (TO-261)
- Description: MOSFET P-CH 20V 10A SOT-223
- COMPETITIVE PRICE and DELIVERY TIME
- Order with confidence, there are no lead times for in-stock products.
Download Datasheet (PDF)
NVF6P02T3G Specifications:
- MfrPart.: NVF6P02T3G
- Mfr: onsemi
- Description: MOSFET P-CH 20V 10A SOT-223
- Product Category: Discrete Semiconductor Products~Transistors - FETs, MOSFETs - Single
- Package: Tape & Reel (TR),Cut Tape (CT)
- Series: Automotive, AEC-Q101
- PartStatus: Not For New Designs
- FETType: P-Channel
- Technology: MOSFET (Metal Oxide)
- DraintoSourceVoltage(Vdss): 20 V
- Current-ContinuousDrain(Id)@25°C: 10A (Ta)
- DriveVoltage(MaxRdsOnMinRdsOn): 2.5V, 4.5V
- RdsOn(Max)@IdVgs: 50mOhm @ 6A, 4.5V
- Vgs(th)(Max)@Id: 1V @ 250µA
- GateCharge(Qg)(Max)@Vgs: 20 nC @ 4.5 V
- Vgs(Max): ±8V
- InputCapacitance(Ciss)(Max)@Vds: 1200 pF @ 16 V
- FETFeature: -
- PowerDissipation(Max): 8.3W (Ta)
- OperatingTemperature: -55°C ~ 150°C (TJ)
- MountingType: Surface Mount
- SupplierDevicePackage: SOT-223 (TO-261)
- NVF6P02T3G onsemi (ON), MOSFET P-CH 20V 10A SOT-223, Discrete Semiconductor Products~Transistors - FETs, MOSFETs - Single
NVF6P02T3G, onsemi authentic parts in stock from onsemi (ON) authorized distributors, order today, can ship immediately.
