NVF2201NT1G Images
- Manufacturer: onsemi (ON)
- Category: Discrete Semiconductor Products~Transistors - FETs, MOSFETs - Single SupplierDevicePackage: SC-70-3 (SOT323)
- Description: MOSFET N-CH 20V 300MA SC70-3
- COMPETITIVE PRICE and DELIVERY TIME
- Order with confidence, there are no lead times for in-stock products.
Download Datasheet (PDF)
NVF2201NT1G Specifications:
- MfrPart.: NVF2201NT1G
- Mfr: onsemi
- Description: MOSFET N-CH 20V 300MA SC70-3
- Product Category: Discrete Semiconductor Products~Transistors - FETs, MOSFETs - Single
- Package: Tape & Reel (TR),Cut Tape (CT)
- Series: Automotive, AEC-Q101
- PartStatus: Obsolete
- FETType: N-Channel
- Technology: MOSFET (Metal Oxide)
- DraintoSourceVoltage(Vdss): 20 V
- Current-ContinuousDrain(Id)@25°C: 300mA (Ta)
- DriveVoltage(MaxRdsOnMinRdsOn): 4.5V, 10V
- RdsOn(Max)@IdVgs: 1Ohm @ 300mA, 10V
- Vgs(th)(Max)@Id: 2.4V @ 250µA
- GateCharge(Qg)(Max)@Vgs: -
- Vgs(Max): ±20V
- InputCapacitance(Ciss)(Max)@Vds: 45 pF @ 5 V
- FETFeature: -
- PowerDissipation(Max): 150mW (Ta)
- OperatingTemperature: -55°C ~ 150°C (TJ)
- MountingType: Surface Mount
- SupplierDevicePackage: SC-70-3 (SOT323)
- NVF2201NT1G onsemi (ON), MOSFET N-CH 20V 300MA SC70-3, Discrete Semiconductor Products~Transistors - FETs, MOSFETs - Single
NVF2201NT1G, onsemi authentic parts in stock from onsemi (ON) authorized distributors, order today, can ship immediately.
