NVD6824NLT4G Images
- Manufacturer: onsemi (ON)
- Category: Discrete Semiconductor Products~Transistors - FETs, MOSFETs - Single SupplierDevicePackage: DPAK
- Description: MOSFET N-CH 100V 8.5A/41A DPAK
- COMPETITIVE PRICE and DELIVERY TIME
- Order with confidence, there are no lead times for in-stock products.
Download Datasheet (PDF)
NVD6824NLT4G Specifications:
- MfrPart.: NVD6824NLT4G
- Mfr: onsemi
- Description: MOSFET N-CH 100V 8.5A/41A DPAK
- Product Category: Discrete Semiconductor Products~Transistors - FETs, MOSFETs - Single
- Package: Tape & Reel (TR),Cut Tape (CT)
- Series: -
- PartStatus: Obsolete
- FETType: N-Channel
- Technology: MOSFET (Metal Oxide)
- DraintoSourceVoltage(Vdss): 100 V
- Current-ContinuousDrain(Id)@25°C: 8.5A (Ta), 41A (Tc)
- DriveVoltage(MaxRdsOnMinRdsOn): 4.5V, 10V
- RdsOn(Max)@IdVgs: 20mOhm @ 20A, 10V
- Vgs(th)(Max)@Id: 2.5V @ 250µA
- GateCharge(Qg)(Max)@Vgs: 66 nC @ 10 V
- Vgs(Max): ±20V
- InputCapacitance(Ciss)(Max)@Vds: 3468 pF @ 25 V
- FETFeature: -
- PowerDissipation(Max): 3.9W (Ta), 90W (Tc)
- OperatingTemperature: -55°C ~ 175°C (TJ)
- MountingType: Surface Mount
- SupplierDevicePackage: DPAK
- NVD6824NLT4G onsemi (ON), MOSFET N-CH 100V 8.5A/41A DPAK, Discrete Semiconductor Products~Transistors - FETs, MOSFETs - Single
NVD6824NLT4G, onsemi authentic parts in stock from onsemi (ON) authorized distributors, order today, can ship immediately.
