NVD5807NT4G onsemi MOSFET N-CH 40V 23A DPAK
NVD5807NT4G Images
NVD5807NT4G Images
  • Manufacturer: onsemi (ON)
  • Category: Discrete Semiconductor Products~Transistors - FETs, MOSFETs - Single SupplierDevicePackage: DPAK
  • Description: MOSFET N-CH 40V 23A DPAK
  • COMPETITIVE PRICE and DELIVERY TIME
  • Order with confidence, there are no lead times for in-stock products.
Quickly Quote for You to Meet Your Target Price, Support Small Order Quantity with Fast Quick Delivery.
Download Datasheet (PDF)
NVD5807NT4G Datasheet
ELECTRONIC COMPONENTS, CHOOSE NHE ELECTRONICS
NVD5807NT4G Specifications:
  • MfrPart.: NVD5807NT4G
  • Mfr: onsemi
  • Description: MOSFET N-CH 40V 23A DPAK
  • Product Category: Discrete Semiconductor Products~Transistors - FETs, MOSFETs - Single
  • Package: Tape & Reel (TR),Cut Tape (CT)
  • Series: -
  • PartStatus: Obsolete
  • FETType: N-Channel
  • Technology: MOSFET (Metal Oxide)
  • DraintoSourceVoltage(Vdss): 40 V
  • Current-ContinuousDrain(Id)@25°C: 23A (Tc)
  • DriveVoltage(MaxRdsOnMinRdsOn): 4.5V, 10V
  • RdsOn(Max)@IdVgs: 31mOhm @ 5A, 10V
  • Vgs(th)(Max)@Id: 2.5V @ 250µA
  • GateCharge(Qg)(Max)@Vgs: 20 nC @ 10 V
  • Vgs(Max): ±20V
  • InputCapacitance(Ciss)(Max)@Vds: 603 pF @ 25 V
  • FETFeature: -
  • PowerDissipation(Max): 33W (Tc)
  • OperatingTemperature: -55°C ~ 175°C (TJ)
  • MountingType: Surface Mount
  • SupplierDevicePackage: DPAK
  • NVD5807NT4G onsemi (ON), MOSFET N-CH 40V 23A DPAK, Discrete Semiconductor Products~Transistors - FETs, MOSFETs - Single
NVD5807NT4G, onsemi authentic parts in stock from onsemi (ON) authorized distributors, order today, can ship immediately.
