NVD4809NHT4G Images
- Manufacturer: onsemi (ON)
- Category: Discrete Semiconductor Products~Transistors - FETs, MOSFETs - Single SupplierDevicePackage: DPAK-3
- Description: MOSFET N-CH 30V 9A/58A DPAK-3
- COMPETITIVE PRICE and DELIVERY TIME
- Order with confidence, there are no lead times for in-stock products.
Download Datasheet (PDF)
NVD4809NHT4G Specifications:
- MfrPart.: NVD4809NHT4G
- Mfr: onsemi
- Description: MOSFET N-CH 30V 9A/58A DPAK-3
- Product Category: Discrete Semiconductor Products~Transistors - FETs, MOSFETs - Single
- Package: Tape & Reel (TR)
- Series: -
- PartStatus: Obsolete
- FETType: N-Channel
- Technology: MOSFET (Metal Oxide)
- DraintoSourceVoltage(Vdss): 30 V
- Current-ContinuousDrain(Id)@25°C: 9A (Ta), 58A (Tc)
- DriveVoltage(MaxRdsOnMinRdsOn): 4.5V, 11.5V
- RdsOn(Max)@IdVgs: 9mOhm @ 30A, 10V
- Vgs(th)(Max)@Id: 2.5V @ 250µA
- GateCharge(Qg)(Max)@Vgs: 44 nC @ 11.5 V
- Vgs(Max): ±20V
- InputCapacitance(Ciss)(Max)@Vds: 2155 pF @ 12 V
- FETFeature: -
- PowerDissipation(Max): 1.3W (Ta), 52W (Tc)
- OperatingTemperature: -55°C ~ 175°C (TJ)
- MountingType: Surface Mount
- SupplierDevicePackage: DPAK-3
- NVD4809NHT4G onsemi (ON), MOSFET N-CH 30V 9A/58A DPAK-3, Discrete Semiconductor Products~Transistors - FETs, MOSFETs - Single
