NVB5860NT4G Images
- Manufacturer: onsemi (ON)
- Category: Discrete Semiconductor Products~Transistors - FETs, MOSFETs - Single SupplierDevicePackage: D²PAK
- Description: MOSFET N-CH 60V 220A D2PAK-3
- COMPETITIVE PRICE and DELIVERY TIME
- Order with confidence, there are no lead times for in-stock products.
Download Datasheet (PDF)
NVB5860NT4G Specifications:
- MfrPart.: NVB5860NT4G
- Mfr: onsemi
- Description: MOSFET N-CH 60V 220A D2PAK-3
- Product Category: Discrete Semiconductor Products~Transistors - FETs, MOSFETs - Single
- Package: Tape & Reel (TR)
- Series: -
- PartStatus: Obsolete
- FETType: N-Channel
- Technology: MOSFET (Metal Oxide)
- DraintoSourceVoltage(Vdss): 60 V
- Current-ContinuousDrain(Id)@25°C: 220A (Tc)
- DriveVoltage(MaxRdsOnMinRdsOn): 10V
- RdsOn(Max)@IdVgs: 3mOhm @ 75A, 10V
- Vgs(th)(Max)@Id: 4V @ 250µA
- GateCharge(Qg)(Max)@Vgs: 180 nC @ 10 V
- Vgs(Max): ±20V
- InputCapacitance(Ciss)(Max)@Vds: 10760 pF @ 25 V
- FETFeature: -
- PowerDissipation(Max): 283W (Tc)
- OperatingTemperature: -55°C ~ 175°C (TJ)
- MountingType: Surface Mount
- SupplierDevicePackage: D²PAK
- NVB5860NT4G onsemi (ON), MOSFET N-CH 60V 220A D2PAK-3, Discrete Semiconductor Products~Transistors - FETs, MOSFETs - Single
NVB5860NT4G, onsemi authentic parts in stock from onsemi (ON) authorized distributors, order today, can ship immediately.
