NVATS5A108PLZT4G Images
- Manufacturer: onsemi (ON)
- Category: Discrete Semiconductor Products~Transistors - FETs, MOSFETs - Single SupplierDevicePackage: ATPAK
- Description: MOSFET P-CHANNEL 40V 77A ATPAK
- COMPETITIVE PRICE and DELIVERY TIME
- Order with confidence, there are no lead times for in-stock products.
Download Datasheet (PDF)
NVATS5A108PLZT4G Specifications:
- MfrPart.: NVATS5A108PLZT4G
- Mfr: onsemi
- Description: MOSFET P-CHANNEL 40V 77A ATPAK
- Product Category: Discrete Semiconductor Products~Transistors - FETs, MOSFETs - Single
- Package: Tape & Reel (TR)
- Series: -
- PartStatus: Active
- FETType: P-Channel
- Technology: MOSFET (Metal Oxide)
- DraintoSourceVoltage(Vdss): 40 V
- Current-ContinuousDrain(Id)@25°C: 77A (Ta)
- DriveVoltage(MaxRdsOnMinRdsOn): 4.5V, 10V
- RdsOn(Max)@IdVgs: 10.4mOhm @ 35A, 10V
- Vgs(th)(Max)@Id: 2.6V @ 1mA
- GateCharge(Qg)(Max)@Vgs: 79.5 nC @ 10 V
- Vgs(Max): ±20V
- InputCapacitance(Ciss)(Max)@Vds: 3850 pF @ 20 V
- FETFeature: -
- PowerDissipation(Max): 72W (Tc)
- OperatingTemperature: -55°C ~ 175°C (TJ)
- MountingType: Surface Mount
- SupplierDevicePackage: ATPAK
- NVATS5A108PLZT4G onsemi (ON), MOSFET P-CHANNEL 40V 77A ATPAK, Discrete Semiconductor Products~Transistors - FETs, MOSFETs - Single
