NTTFS5C680NLTAG Images
- Manufacturer: onsemi (ON)
- Category: Discrete Semiconductor Products~Transistors - FETs, MOSFETs - Single SupplierDevicePackage: 8-WDFN (3.3x3.3)
- Description: MOSFET N-CH 60V 7.82A/20A 8WDFN
- COMPETITIVE PRICE and DELIVERY TIME
- Order with confidence, there are no lead times for in-stock products.
Download Datasheet (PDF)
NTTFS5C680NLTAG Specifications:
- MfrPart.: NTTFS5C680NLTAG
- Mfr: onsemi
- Description: MOSFET N-CH 60V 7.82A/20A 8WDFN
- Product Category: Discrete Semiconductor Products~Transistors - FETs, MOSFETs - Single
- Package: Tape & Reel (TR)
- Series: -
- PartStatus: Active
- FETType: N-Channel
- Technology: MOSFET (Metal Oxide)
- DraintoSourceVoltage(Vdss): 60 V
- Current-ContinuousDrain(Id)@25°C: 7.82A (Ta), 20A (Tc)
- DriveVoltage(MaxRdsOnMinRdsOn): 4.5V, 10V
- RdsOn(Max)@IdVgs: 26.5mOhm @ 10A, 10V
- Vgs(th)(Max)@Id: 2.2V @ 13µA
- GateCharge(Qg)(Max)@Vgs: 6 nC @ 10 V
- Vgs(Max): ±20V
- InputCapacitance(Ciss)(Max)@Vds: 327 pF @ 25 V
- FETFeature: -
- PowerDissipation(Max): 3W (Ta), 20W (Tc)
- OperatingTemperature: -55°C ~ 175°C (TJ)
- MountingType: Surface Mount
- SupplierDevicePackage: 8-WDFN (3.3x3.3)
- NTTFS5C680NLTAG onsemi (ON), MOSFET N-CH 60V 7.82A/20A 8WDFN, Discrete Semiconductor Products~Transistors - FETs, MOSFETs - Single
