NTTFS4C05NTWG Images
- Manufacturer: onsemi (ON)
- Category: Discrete Semiconductor Products~Transistors - FETs, MOSFETs - Single SupplierDevicePackage: 8-WDFN (3.3x3.3)
- Description: MOSFET N-CH 30V 12A/75A 8WDFN
- COMPETITIVE PRICE and DELIVERY TIME
- Order with confidence, there are no lead times for in-stock products.
Download Datasheet (PDF)
NTTFS4C05NTWG Specifications:
- MfrPart.: NTTFS4C05NTWG
- Mfr: onsemi
- Description: MOSFET N-CH 30V 12A/75A 8WDFN
- Product Category: Discrete Semiconductor Products~Transistors - FETs, MOSFETs - Single
- Package: Tape & Reel (TR)
- Series: -
- PartStatus: Active
- FETType: N-Channel
- Technology: MOSFET (Metal Oxide)
- DraintoSourceVoltage(Vdss): 30 V
- Current-ContinuousDrain(Id)@25°C: 12A (Ta), 75A (Tc)
- DriveVoltage(MaxRdsOnMinRdsOn): 4.5V, 10V
- RdsOn(Max)@IdVgs: 3.6mOhm @ 30A, 10V
- Vgs(th)(Max)@Id: 2.2V @ 250µA
- GateCharge(Qg)(Max)@Vgs: 31 nC @ 10 V
- Vgs(Max): ±20V
- InputCapacitance(Ciss)(Max)@Vds: 1988 pF @ 15 V
- FETFeature: -
- PowerDissipation(Max): 820mW (Ta), 33W (Tc)
- OperatingTemperature: -55°C ~ 150°C (TJ)
- MountingType: Surface Mount
- SupplierDevicePackage: 8-WDFN (3.3x3.3)
- NTTFS4C05NTWG onsemi (ON), MOSFET N-CH 30V 12A/75A 8WDFN, Discrete Semiconductor Products~Transistors - FETs, MOSFETs - Single
NTTFS4C05NTWG, onsemi authentic parts in stock from onsemi (ON) authorized distributors, order today, can ship immediately.
