NTTFS3D7N06HLTWG Images
- Manufacturer: onsemi (ON)
- Category: Discrete Semiconductor Products~Transistors - FETs, MOSFETs - Single SupplierDevicePackage: 8-PQFN (3.3x3.3)
- Description: MOSFET N-CH 60V 16A/103A 8PQFN
- COMPETITIVE PRICE and DELIVERY TIME
- Order with confidence, there are no lead times for in-stock products.
Download Datasheet (PDF)
NTTFS3D7N06HLTWG Specifications:
- MfrPart.: NTTFS3D7N06HLTWG
- Mfr: onsemi
- Description: MOSFET N-CH 60V 16A/103A 8PQFN
- Product Category: Discrete Semiconductor Products~Transistors - FETs, MOSFETs - Single
- Package: Tape & Reel (TR),Cut Tape (CT)
- Series: -
- PartStatus: Active
- FETType: N-Channel
- Technology: MOSFET (Metal Oxide)
- DraintoSourceVoltage(Vdss): 60 V
- Current-ContinuousDrain(Id)@25°C: 16A (Ta), 103A (Tc)
- DriveVoltage(MaxRdsOnMinRdsOn): 4.5V, 10V
- RdsOn(Max)@IdVgs: 3.9mOhm @ 23A, 10V
- Vgs(th)(Max)@Id: 2V @ 120µA
- GateCharge(Qg)(Max)@Vgs: 32.7 nC @ 10 V
- Vgs(Max): ±20V
- InputCapacitance(Ciss)(Max)@Vds: 2383 pF @ 30 V
- FETFeature: -
- PowerDissipation(Max): 2.2W (Ta), 83W (Tc)
- OperatingTemperature: -55°C ~ 150°C (TJ)
- MountingType: Surface Mount
- SupplierDevicePackage: 8-PQFN (3.3x3.3)
- NTTFS3D7N06HLTWG onsemi (ON), MOSFET N-CH 60V 16A/103A 8PQFN, Discrete Semiconductor Products~Transistors - FETs, MOSFETs - Single
NTTFS3D7N06HLTWG, onsemi authentic parts in stock from onsemi (ON) authorized distributors, order today, can ship immediately.
