NTTFS2D8N04HLTAG Images
- Manufacturer: onsemi (ON)
- Category: Discrete Semiconductor Products~Transistors - FETs, MOSFETs - Single SupplierDevicePackage: 8-WDFN (3.3x3.3)
- Description: MOSFET N-CH 40V 24A/104A 8WDFN
- COMPETITIVE PRICE and DELIVERY TIME
- Order with confidence, there are no lead times for in-stock products.
Download Datasheet (PDF)
NTTFS2D8N04HLTAG Specifications:
- MfrPart.: NTTFS2D8N04HLTAG
- Mfr: onsemi
- Description: MOSFET N-CH 40V 24A/104A 8WDFN
- Product Category: Discrete Semiconductor Products~Transistors - FETs, MOSFETs - Single
- Package: Tape & Reel (TR)
- Series: -
- PartStatus: Active
- FETType: N-Channel
- Technology: MOSFET (Metal Oxide)
- DraintoSourceVoltage(Vdss): 40 V
- Current-ContinuousDrain(Id)@25°C: 24A (Ta), 104A (Tc)
- DriveVoltage(MaxRdsOnMinRdsOn): 4.5V, 10V
- RdsOn(Max)@IdVgs: 2.75mOhm @ 16A, 10V
- Vgs(th)(Max)@Id: 2V @ 80µA
- GateCharge(Qg)(Max)@Vgs: 32 nC @ 10 V
- Vgs(Max): ±20V
- InputCapacitance(Ciss)(Max)@Vds: 1960 pF @ 20 V
- FETFeature: -
- PowerDissipation(Max): 3.2W (Ta), 63W (Tc)
- OperatingTemperature: -55°C ~ 150°C (TJ)
- MountingType: Surface Mount
- SupplierDevicePackage: 8-WDFN (3.3x3.3)
- NTTFS2D8N04HLTAG onsemi (ON), MOSFET N-CH 40V 24A/104A 8WDFN, Discrete Semiconductor Products~Transistors - FETs, MOSFETs - Single
