NTTFS024N06CTAG Images
- Manufacturer: onsemi (ON)
- Category: Discrete Semiconductor Products~Transistors - FETs, MOSFETs - Single SupplierDevicePackage: 8-WDFN (3.3x3.3)
- Description: MOSFET N-CH 60V 7A/24A 8WDFN
- COMPETITIVE PRICE and DELIVERY TIME
- Order with confidence, there are no lead times for in-stock products.
Download Datasheet (PDF)
NTTFS024N06CTAG Specifications:
- MfrPart.: NTTFS024N06CTAG
- Mfr: onsemi
- Description: MOSFET N-CH 60V 7A/24A 8WDFN
- Product Category: Discrete Semiconductor Products~Transistors - FETs, MOSFETs - Single
- Package: Tape & Reel (TR)
- Series: -
- PartStatus: Active
- FETType: N-Channel
- Technology: MOSFET (Metal Oxide)
- DraintoSourceVoltage(Vdss): 60 V
- Current-ContinuousDrain(Id)@25°C: 7A (Ta), 24A (Tc)
- DriveVoltage(MaxRdsOnMinRdsOn): 10V
- RdsOn(Max)@IdVgs: 22.6mOhm @ 3A, 10V
- Vgs(th)(Max)@Id: 4V @ 20µA
- GateCharge(Qg)(Max)@Vgs: 5.7 nC @ 10 V
- Vgs(Max): ±20V
- InputCapacitance(Ciss)(Max)@Vds: 333 pF @ 30 V
- FETFeature: -
- PowerDissipation(Max): 2.5W (Ta), 28W (Tc)
- OperatingTemperature: -55°C ~ 175°C (TJ)
- MountingType: Surface Mount
- SupplierDevicePackage: 8-WDFN (3.3x3.3)
- NTTFS024N06CTAG onsemi (ON), MOSFET N-CH 60V 7A/24A 8WDFN, Discrete Semiconductor Products~Transistors - FETs, MOSFETs - Single
