NTTFS022N15MC Images
- Manufacturer: onsemi (ON)
- Category: Discrete Semiconductor Products~Transistors - FETs, MOSFETs - Single SupplierDevicePackage: 8-PQFN (3.3x3.3)
- Description: POWER MOSFET, N CHANNEL, 150V, 3
- COMPETITIVE PRICE and DELIVERY TIME
- Order with confidence, there are no lead times for in-stock products.
Download Datasheet (PDF)
NTTFS022N15MC Specifications:
- MfrPart.: NTTFS022N15MC
- Mfr: onsemi
- Description: POWER MOSFET, N CHANNEL, 150V, 3
- Product Category: Discrete Semiconductor Products~Transistors - FETs, MOSFETs - Single
- Package: Tape & Reel (TR),Cut Tape (CT)
- Series: PowerTrench®
- PartStatus: Active
- FETType: N-Channel
- Technology: MOSFET (Metal Oxide)
- DraintoSourceVoltage(Vdss): 150 V
- Current-ContinuousDrain(Id)@25°C: 7.4A (Ta), 37.2A (Tc)
- DriveVoltage(MaxRdsOnMinRdsOn): 8V, 10V
- RdsOn(Max)@IdVgs: 22mOhm @ 18A, 10V
- Vgs(th)(Max)@Id: 4.5V @ 100µA
- GateCharge(Qg)(Max)@Vgs: 17 nC @ 10 V
- Vgs(Max): ±20V
- InputCapacitance(Ciss)(Max)@Vds: 1315 pF @ 75 V
- FETFeature: -
- PowerDissipation(Max): 1.2W (Ta), 71.4W (Tc)
- OperatingTemperature: -55°C ~ 175°C (TJ)
- MountingType: Surface Mount
- SupplierDevicePackage: 8-PQFN (3.3x3.3)
- NTTFS022N15MC onsemi (ON), POWER MOSFET, N CHANNEL, 150V, 3, Discrete Semiconductor Products~Transistors - FETs, MOSFETs - Single
NTTFS022N15MC, onsemi authentic parts in stock from onsemi (ON) authorized distributors, order today, can ship immediately.
