NTTFS015P03P8ZTWG Images
- Manufacturer: onsemi (ON)
- Category: Discrete Semiconductor Products~Transistors - FETs, MOSFETs - Single SupplierDevicePackage: 8-WDFN (3.3x3.3)
- Description: MOSFET P-CH 30V 13.4A/47.6A 8DFN
- COMPETITIVE PRICE and DELIVERY TIME
- Order with confidence, there are no lead times for in-stock products.
Download Datasheet (PDF)
NTTFS015P03P8ZTWG Specifications:
- MfrPart.: NTTFS015P03P8ZTWG
- Mfr: onsemi
- Description: MOSFET P-CH 30V 13.4A/47.6A 8DFN
- Product Category: Discrete Semiconductor Products~Transistors - FETs, MOSFETs - Single
- Package: Tape & Reel (TR)
- Series: -
- PartStatus: Active
- FETType: P-Channel
- Technology: MOSFET (Metal Oxide)
- DraintoSourceVoltage(Vdss): 30 V
- Current-ContinuousDrain(Id)@25°C: 13.4A (Ta), 47.6A (Tc)
- DriveVoltage(MaxRdsOnMinRdsOn): 4.5V, 10V
- RdsOn(Max)@IdVgs: 9.3mOhm @ 12A, 10V
- Vgs(th)(Max)@Id: 3V @ 250µA
- GateCharge(Qg)(Max)@Vgs: 62.3 nC @ 10 V
- Vgs(Max): ±25V
- InputCapacitance(Ciss)(Max)@Vds: 2706 pF @ 15 V
- FETFeature: -
- PowerDissipation(Max): 2.66W (Ta), 33.8W (Tc)
- OperatingTemperature: -55°C ~ 150°C (TJ)
- MountingType: Surface Mount
- SupplierDevicePackage: 8-WDFN (3.3x3.3)
- NTTFS015P03P8ZTWG onsemi (ON), MOSFET P-CH 30V 13.4A/47.6A 8DFN, Discrete Semiconductor Products~Transistors - FETs, MOSFETs - Single
NTTFS015P03P8ZTWG, onsemi authentic parts in stock from onsemi (ON) authorized distributors, order today, can ship immediately.
